TECHNICAL
DATA COVERING IS-4559-1993
|
|
|
CAPACITY OF RECTIFIER MAX.
|
AXT-300
|
AXT-400
|
AXT-500
|
AXT-600
|
| INPUT
|
|
Supply voltage 3 PH
|
380/415/440
|
380/415/440
|
380/415/440
|
380/415/440
|
|
Primary Current at Max. Output
|
30A
|
40A
|
50A
|
60A
|
|
OUTPUT
|
D.C.
|
D.C.
|
D.C.
|
D.C.
|
|
Open circuit Voltage
|
80
|
85
|
85
|
90
|
|
Max. Continuous Current at 100%
Duty Cycle
|
225
|
300
|
340
|
420
|
|
Max. Continuous at
60% Duty Cycle
|
300
|
400
|
500
|
600
|
|
KVA-Max. Continuous
|
15
|
20
|
25
|
30
|
|
KVA- Max.
|
20
|
26
|
33
|
43.2
|
|
Welding Current range
(in Two Ranges)
|
10-300A
|
10-400A
|
10-500A
|
10-600A
|
| GENERAL
|
|
Max. Ambient Temp. to
which Rating Apply
|
40 C
|
40 C
|
40 C
|
40 C
|
|
Class of Cooling
|
H
|
H
|
H
|
H
|
|
Type of Cooling
|
Forced Air Cooled
|
Forced Air Cooled
|
Forced Air Cooled
|
Forced Air Cooled
|
|
Approx. Dimensions
(LxWxH) mm
|
658 x 762 x 508
|
711 x 762 x 546
|
711 x 762 x 546
|
736 x 762 x 596
|
|
Approx. Weight Kg.
|
200
|
220
|
240
|
265
|
| |
| Note:
In view of continuous development, we reserve the
right to modify the design and dimensions without
notice. Duty cycles are applicable for 5 minutes
at 40 °C. |
